40098 DIP Hex 3-State Inverting Buffer

40098 DIP Hex 3-State Inverting Buffer

The 40098 DIP Hex 3-State Inverting Buffer is a versatile logic IC. It belongs to the 40 Series family. This chip has six inverting buffers with three-state outputs. It is perfect for digital electronics projects. Hobbyists and engineers love its reliability.

This buffer inverts input signals. It also offers high-impedance output states. This feature allows multiple outputs to share a bus. It prevents signal conflicts. The 40098 works with a wide voltage range. It is easy to use in breadboards and PCBs.

The Hex 3-State Inverting Buffer is a key part of bus management. It takes a logic high input and outputs a logic low. It takes a logic low input and outputs a logic high. The three-state output can be high, low, or high-impedance. The high-impedance state disconnects the output from the bus. This lets many devices talk on one line without interference. The chip uses standard CMOS technology. It is very power efficient. It works well with other 40 Series chips. You can cascade multiple buffers for more outputs. The design is simple and robust. It handles a wide temperature range. This makes it suitable for industrial use. The Hex 3-State Inverting Buffer is a workhorse for digital logic.

Key Features

• Six inverting buffers with three-state outputs for bus-oriented systems
• Wide operating voltage range from 3V to 15V for flexibility
• Standard DIP-16 package for easy prototyping and integration
• High noise immunity ensures stable performance in noisy environments
• Low power consumption extends battery life in portable devices
• Direct replacement for many legacy 4000 series designs

Use Cases

Use the 40098 in microcontroller projects. It drives LEDs or relays. It also works as a level shifter. This IC is great for data buses. It is ideal for robotics and automation. Students and makers use it in labs. Engineers use it in test equipment. It works well in alarm systems. It can buffer clock signals. It is perfect for memory address lines. The Hex 3-State Inverting Buffer helps in multiplexing. It is a common choice for hobbyists. It is also used in industrial controls. Anyone who needs reliable signal inversion will love it.

Order your 40098 DIP Hex 3-State Inverting Buffer today. It is in stock at Electra Store. Get fast shipping and great support. Upgrade your project with this reliable IC now. Do not wait to start building. This Hex 3-State Inverting Buffer will make your designs better. It is a small part with a big impact. Buy it today and see the difference.
