4514 DIP 1-of-16 Decoder Demultiplexer Active High Output

The 4514 DIP 1-of-16 decoder is a CMOS integrated circuit. It converts a 4-bit binary input into one of 16 active high outputs. This chip is ideal for digital logic projects. It works well in multiplexing and demultiplexing applications. Hobbyists and engineers trust this 45 series part.

This 1-of-16 decoder takes a four-bit binary address. It then activates exactly one output pin. The active high output means the selected pin goes high. All other pins stay low. This makes it perfect for selecting one device from sixteen. The chip uses CMOS technology. This keeps power consumption very low. It also provides high noise immunity. The 1-of-16 decoder can drive loads directly. You do not need extra inverters. The DIP-24 package fits standard breadboards. It also fits sockets and perfboards. The wide voltage range works with many systems. You can use it from 3V to 15V. This 1-of-16 decoder is a reliable workhorse for digital design.

This 1-of-16 decoder uses active high outputs. It comes in a DIP-24 package. The chip is easy to breadboard. It operates on a wide voltage range. Use it for memory decoding or data routing. It simplifies complex digital designs.

Key Features

• CMOS technology for low power consumption and high noise immunity
• Active high outputs drive loads directly without extra inverters
• Wide supply voltage range from 3V to 15V for flexible use
• Standard DIP-24 package fits breadboards and sockets easily
• Compatible with TTL logic levels for mixed-signal projects
• Fast propagation delay for high-speed digital circuits

Use Cases

This 1-of-16 decoder works great in address decoding. It selects one of 16 memory chips. It also drives LED displays or relays. Students use it in lab experiments. Engineers use it in industrial control systems. Hobbyists use it for home automation projects. It is perfect for routing data signals. It also works for selecting sensors. The 1-of-16 decoder is a key part of many digital systems. Anyone building complex logic will need this chip.

Order your 4514 DIP 1-of-16 decoder today. Electra Store ships fast. Get this essential 45 series chip now. Build better digital circuits with confidence. Do not wait to start your next project. Add this 1-of-16 decoder to your cart right now. You will love the performance and reliability.
