7407 DIP Hex Buffer / Driver With 30V Open Collector Outputs

7407 DIP Hex Buffer / Driver With 30V Open Collector Outputs

The 7407 DIP Hex Buffer is a versatile logic IC. It features six independent buffers. Each buffer has an open collector output. This design allows up to 30V operation. It is perfect for driving relays, LEDs, or high-voltage logic. Hobbyists and engineers trust this chip for reliable performance.

This buffer driver works with TTL and CMOS inputs. It can sink up to 40mA per output. The open collector outputs let you connect external pull-up resistors. This gives you flexibility in voltage levels. Use it to interface between low-voltage logic and higher-voltage loads. The 7407 DIP Hex Buffer handles many tasks with ease. It can drive multiple outputs at once. Each buffer works independently. This means you can mix signals safely. The chip is built for durability. It withstands tough conditions in labs or workshops. You can rely on it for consistent results. The open collector design prevents damage from voltage spikes. It also allows easy connection to different power sources. This makes the 7407 DIP Hex Buffer a top choice for complex circuits.

Key Features

• Six independent buffers with open collector outputs
• Output voltage rating up to 30V for high-voltage applications
• High sink current of 40mA per output for driving loads
• Wide operating voltage range from 4.75V to 5.25V
• Standard DIP-14 package for easy breadboarding
• Compatible with TTL and CMOS logic families

Use Cases

The 7407 DIP Hex Buffer is ideal for driving relays, lamps, or solenoids. It also works well in level shifting circuits. Use it in industrial controls, automation projects, or hobby electronics. Engineers choose it for its robust open collector design. Typical buyers include robotics enthusiasts, lab technicians, and repair shops. Students use it in educational kits. Professionals rely on it for prototyping. The 7407 DIP Hex Buffer fits many needs. It is great for signal conditioning. It also works in motor control systems. You can use it in audio circuits too. The chip is versatile and easy to use. It helps you bridge different voltage levels. This saves time and reduces errors. Many buyers stock it for future projects. It is a staple in any electronics toolbox.

Upgrade your project today with the 7407 DIP Hex Buffer. It delivers reliable performance for demanding tasks. Order now from Electra Store and get fast shipping. Your satisfaction is guaranteed. Do not wait. Add the 7407 DIP Hex Buffer to your cart now. It will boost your circuit design. You will love the results. Act today and enjoy great value.
