74249 DIP BCD To 7-Segment Decoder / Driver With Open Collector Outputs

74249 DIP BCD to 7-Segment Decoder Driver with Open Collector Outputs

The 74249 7-Segment Decoder Driver is a DIP IC from the 74 Series. It converts BCD input to 7-segment display signals. This driver features open collector outputs. It is perfect for hobbyists and engineers. Use it in digital clocks, counters, and more.

This 7-Segment Decoder Driver takes a four-bit binary coded decimal input. It then decodes that input into seven individual output signals. These signals drive the segments of a numeric display. The open collector outputs are a key advantage. They allow the IC to sink higher currents than standard outputs. This means you can drive larger or brighter displays. The 7-Segment Decoder Driver also includes a lamp test function. This lets you verify all segments are working. It has a blanking input to turn off the display. This saves power in battery applications. The IC works with common-anode LED displays. It is a robust and reliable choice for many projects.

Key Features

• Complete BCD to 7-segment decoding on a single chip
• Open collector outputs rated for high current drive
• DIP-16 package for easy breadboard and PCB prototyping
• Lamp test and blanking inputs for display control
• Wide operating voltage from 4.75V to 5.25V
• Directly drives common-anode 7-segment LED displays

Use Cases

This 7-Segment Decoder Driver is ideal for digital clocks, scoreboards, and measurement displays. It works well in educational kits and prototyping. Engineers use it for control panels and instrumentation. Hobbyists love it for Arduino and Raspberry Pi projects. It is also great for industrial counters and timers. Students use it to learn digital logic. The 7-Segment Decoder Driver suits any project needing a numeric readout. It is a staple in electronics labs and workshops.

Order the 74249 7-Segment Decoder Driver today. It boosts your project reliability. Fast shipping from Electra Store. Get yours now and build better displays. This 7-Segment Decoder Driver is in stock and ready to ship. Add it to your cart for quick delivery. Your next project deserves this quality component. Click to order now and start building.
