74564 DIP 8-Bit D-Type Edge-Triggered Register With Inverting Three-State Outputs

74564 DIP 8-Bit D-Type Edge-Triggered Register With Inverting Three-State Outputs

The 74564 DIP 8-Bit D-Type Edge-Triggered Register is a high-performance logic IC. It stores eight bits of data. The inverting three-state outputs allow easy bus connection. This chip is perfect for digital designers and hobbyists. It works in many electronic projects.

This register captures data on the rising edge of the clock. The inverted outputs give design flexibility. Three-state outputs let you share data lines safely. You can use it in counters, buffers, and memory systems. It is a reliable part from the 74 series.

This 8-Bit D-Type Register works as a temporary data holder. It accepts eight input signals at once. The clock edge triggers the capture instantly. The inverting outputs flip each bit. This feature is useful for active-low logic. The three-state control disables outputs when needed. This prevents bus conflicts in complex circuits. The chip operates at standard TTL levels. It draws low power for its speed. Designers trust this 8-Bit D-Type Register for consistent results. It handles data rates up to 30 MHz. The DIP package fits standard breadboards. You can test it quickly without soldering. This 8-Bit D-Type Register is a core building block. It simplifies data routing in digital systems.

Key Features

• Eight-bit D-type edge-triggered register for precise data capture
• Inverting three-state outputs for shared bus applications
• DIP package for easy breadboarding and prototyping
• Standard 74 series logic, compatible with TTL systems
• Wide operating voltage range from 4.75V to 5.25V
• High noise immunity for reliable operation in noisy environments

Use Cases

Engineers use this register in data storage and transfer circuits. It works well in microprocessor systems and digital controllers. Hobbyists love it for building custom logic projects. It is also great for educational kits and experiments. This 8-Bit D-Type Register fits into memory address buffers. It works in state machines and sequencers. Students learn digital design with this chip. Professionals use it in industrial control systems. The inverting outputs help with signal inversion tasks. Three-state control simplifies shared data buses. This register is a staple in any logic lab.

Upgrade your project with the 74564 8-Bit D-Type Register. It offers reliable performance and easy integration. Order now from Electra Store for fast shipping and great support. Your designs deserve the best components. This 8-Bit D-Type Register delivers every time. Click add to cart today. We ship within 24 hours. Our team is ready to help you succeed.
