LM7906 Voltage Regulator - Reliable 6V Fixed Output

The LM7906 voltage regulator delivers a stable -6V output. It is ideal for powering negative voltage rails in analog circuits. This fixed regulator requires minimal external components. It suits both hobbyists and professionals.

This regulator ensures clean power for sensitive electronics. It features built-in thermal overload protection and short-circuit current limiting. You get reliable performance in a compact TO-220 package.

The LM7906 voltage regulator works as a negative complement to positive regulators. It converts a negative DC input into a steady -6V output. This process removes noise and ripple from the power source. The device uses internal bandgap reference for high accuracy. It can handle input voltages from -8V to -25V. This makes it versatile for many power supply designs. The regulator maintains output stability even with load changes. You do not need complex external circuitry for operation. Just add two small capacitors for best results. The LM7906 voltage regulator is a workhorse for negative rails.

Key Features

• Fixed -6V output voltage with ±4% tolerance for precise power
• Output current up to 1.5A with proper heat sinking
• Built-in thermal shutdown and short-circuit protection
• Low dropout voltage of 2V typical for efficient operation
• Standard TO-220 package for easy mounting on heatsinks
• Wide operating temperature range from 0°C to 125°C

What's Included

• One LM7906 voltage regulator in TO-220 package
• Product datasheet with pinout and application notes
• Anti-static packaging for safe handling and storage
• Electra Store quality guarantee and support contact

Use Cases

Use the LM7906 voltage regulator in dual-supply power supplies. It works well for op-amp circuits, audio amplifiers, and microcontroller projects. It is also great for repairing vintage electronics that need a -6V rail.

Typical buyers include electronics hobbyists and engineers. Students use it for lab experiments and class projects. Audio enthusiasts need it for clean amplifier power. Industrial technicians rely on it for equipment repairs. The LM7906 voltage regulator fits many negative rail applications. It is a common part for custom power supply builds. Anyone building analog circuits will find it useful.

Order your LM7906 voltage regulator from Electra Store today. We offer fast shipping and great prices. Get stable power for your next project now. This LM7906 voltage regulator is in stock and ready to ship. Do not let a missing negative rail stop your work. Buy now and complete your power supply design. Electra Store backs every purchase with reliable service. Click add to cart and secure your component today.
