Schneider Electric Lexium 26 Servo Drive LXM26DU10M3X

The Schneider Electric Lexium 26 Servo Drive LXM26DU10M3X is a high-performance industrial motion control drive designed to deliver precise speed, position, and torque control for demanding automation applications. Rated at 1kW, this compact servo drive supports both single-phase and three-phase 200–230V AC input, making it a versatile solution for CNC machinery, packaging equipment, robotics, conveyor systems, and automated production lines.

As part of the Lexium 26 series from Schneider Electric, the LXM26DU10M3X features advanced digital servo control technology for smooth, accurate, and highly responsive motor performance. It delivers a continuous output power of 1kW, 7A continuous output current, and 21A peak output current, ensuring reliable operation under dynamic load conditions.

The drive is designed with a compact panel-mount enclosure to save cabinet space while providing integrated protection features for safe and dependable operation. It supports flexible communication and control interfaces, allowing seamless integration into modern industrial automation systems. With high switching frequency and optimized control algorithms, the LXM26DU10M3X improves machine productivity, positioning accuracy, and overall system efficiency.

Ideal for OEM machine builders, automation engineers, and industrial control applications, the Lexium 26 Servo Drive offers outstanding performance, reliability, and ease of integration.

Features:

• 1kW high-performance servo drive

• Supports single and three-phase 200–230V AC

• Precise position, speed, and torque control

• Compact panel-mount industrial design

• Fast dynamic response and stable operation

• Continuous 7A output with 21A peak current

• Integrated protection and safety functions

• Optimized for Schneider Lexium servo motors

Specifications:

• Brand: Schneider Electric

• Series: Lexium 26

• Model: LXM26DU10M3X

• Product Type: Motion servo drive

• Rated Power: 1kW

• Input Voltage: 200–230V AC

• Input Phase: Single-phase / Three-phase

• Continuous Output Current: 7A

• Peak Output Current: 21A (3 seconds)

• Supply Frequency: 50/60Hz

• Mounting Type: Panel mount

• Application: Industrial motion control and automation

Applications:

• CNC machines

• Industrial automation systems

• Packaging machinery

• Robotics and motion control

• Conveyor systems

• Textile and printing machines

• Material handling equipment

• Automated manufacturing lines
