TL494 DIP Mosfet Driver

The TL494 DIP Mosfet Driver is a versatile PWM controller. It is ideal for power supply and motor control projects. This component offers high reliability and performance. Engineers and hobbyists trust it for demanding applications. It works well in inverters and DC-DC converters.

This driver integrates all functions needed for pulse-width modulation. It includes an oscillator, error amplifier, and dead-time control. The TL494 DIP Mosfet Driver operates from 7V to 40V. It delivers precise control with minimal external parts. You can easily design efficient power systems.

The TL494 DIP Mosfet Driver provides complete PWM control in one chip. It drives power MOSFETs directly without extra buffers. The internal oscillator sets the switching frequency. You adjust it with a resistor and capacitor. The error amplifier compares output voltage to a reference. This ensures stable regulation under load changes. Dead-time control prevents shoot-through current. It protects your MOSFETs from damage. The dual outputs can sink or source 200mA each. This drives small transformers or gates directly. The built-in 5V reference simplifies circuit design. You can use it for feedback or biasing. This chip reduces component count and board space. It makes your design simpler and more reliable.

Key Features

• Complete PWM control circuit in a compact DIP package
• Wide supply voltage range from 7V to 40V
• Built-in oscillator with frequency programming via external components
• Dead-time control for improved switching efficiency
• Dual output stages capable of 200mA sink or source current
• Internal reference voltage for accurate regulation

What's Included

• One TL494 DIP Mosfet Driver IC
• Anti-static protective packaging
• Product datasheet with pinout and typical circuits
• Electra Store 5-year warranty card

Use Cases

The TL494 DIP Mosfet Driver suits many projects. Hobbyists build solar charge controllers with it. They also make battery chargers and LED drivers. Engineers use it in industrial power supplies. It works for DC motor speed controllers too. Inverter designs rely on its stable PWM. Robotics enthusiasts choose it for servo control. Audio amplifier power stages benefit from it. The TL494 DIP Mosfet Driver handles 40V systems easily. It is great for automotive electronics. You can use it in telecom power converters. Its flexibility fits both simple and complex designs.

Who It's For

This product is for electronics enthusiasts and professionals. Hobbyists enjoy building power projects at home. Students learn PWM control with this chip. Engineers design efficient power systems with it. Repair technicians replace failed PWM controllers. Makers use it in custom inverters and converters. The TL494 DIP Mosfet Driver is a trusted choice for all skill levels.

Order the TL494 DIP Mosfet Driver from Electra Store today. Enjoy fast shipping and a 5-year warranty. This reliable component will boost your project's performance. Get yours now and build with confidence. Your next power design starts here. Click add to cart and start creating.
