4076 DIP Quad D-Type Register With Tristate Outputs

4076 DIP Quad D-Type Register With Tristate Outputs

The 4076 DIP Quad D-Type Register with Tristate Outputs is a reliable 40 series IC from Electra Store. It stores four bits of data. Engineers and hobbyists use it in digital circuits. This register offers tristate outputs for bus-oriented systems.

This DIP Quad D-Type Register captures data on a clock pulse. Each of the four flip-flops holds one bit. The tristate outputs can be high, low, or high-impedance. This allows many devices to share a data bus without conflict. The master reset pin clears all bits at once. The output enable pin controls when data is sent out. This makes the 4076 DIP Quad D-Type Register perfect for memory mapping and data buffering. It works well in systems that need to isolate outputs. The CMOS design keeps power use very low. You can use it in battery-powered projects too. The wide voltage range adds flexibility for different circuits. This IC is a core part of many digital designs.

Key Features

• Four D-type flip-flops with tristate outputs for flexible bus connections.
• Operates from 3V to 15V, compatible with many logic families.
• Standard DIP-16 package for easy breadboarding and PCB use.
• Low power consumption, typical for CMOS 40 series devices.
• Master reset and output enable controls for precise operation.
• High noise immunity ensures reliable performance in noisy environments.

Use Cases

This register suits microprocessor systems, data buffers, and control panels. It works well in educational kits and industrial automation. Builders use it for temporary data storage in counters and shift registers. Typical buyers include electronics students, robotics enthusiasts, and professional engineers. It is ideal for projects that need clean data transfer. You can use it in alarm systems, digital clocks, or simple computers. The 4076 DIP Quad D-Type Register is a staple in any digital lab.

Order the 4076 DIP Quad D-Type Register with Tristate Outputs today. Electra Store ensures fast delivery and a 5-year warranty. Upgrade your project with this essential 40 series component. Add it to your cart now for quick shipping. Your next build will run smoothly with this reliable IC.
