40175 DIP Quad D-Type Flip Flop

40175 DIP Quad D-Type Flip Flop

The 40175 DIP Quad D-Type Flip Flop is a reliable integrated circuit from Electra Store. It belongs to the 40 Series logic family. This IC stores four bits of data. It is ideal for hobbyists and professionals. Use it in counters, registers, and memory circuits.

This flip flop operates on a wide voltage range. It offers high noise immunity. The DIP package makes it easy to use on breadboards. Each flip flop has a clear input. This resets the output to zero. You can build stable digital systems with it.

The 40175 DIP Quad D-Type Flip Flop captures data on a clock edge. It holds that data until the next clock pulse. This makes it perfect for sequential logic. You can store one bit per flip flop. Four bits total give you flexibility. The clear input forces all outputs low. This is useful for system resets. The buffered outputs drive other chips easily. You can chain multiple 40175 chips together. This creates larger register banks. The wide voltage range works with many power supplies. It also tolerates noisy environments well. The DIP Quad D-Type Flip Flop is a workhorse for digital design. It simplifies complex timing tasks. Beginners and experts alike find it easy to use. The 40175 is a true classic in the 40 Series family.

Key Features

• Four D-type flip flops in a single 16-pin DIP package
• Wide operating voltage range from 3V to 15V
• High noise immunity for reliable performance
• Buffered outputs drive up to 10 LS-TTL loads
• Asynchronous clear input on each flip flop
• Standard 40 Series pinout for easy integration

Use Cases

Engineers use this IC in data storage applications. It works well in shift registers and frequency dividers. Students build digital clocks and counters with it. The 40175 is a staple in educational kits. It also fits in industrial control circuits. Hobbyists use it for LED chasers and state machines. It is great for prototyping new ideas. The DIP Quad D-Type Flip Flop suits any project needing memory. It is common in robotics and automation. Teachers use it to explain flip flop theory. The 40175 is a versatile part for many fields.

Order the 40175 DIP Quad D-Type Flip Flop today. Electra Store offers fast shipping and great prices. Add this essential IC to your cart now. Build your next project with confidence. The DIP Quad D-Type Flip Flop is ready to ship. Do not wait to start your design. Get the 40175 now and see the difference.
