7403 DIP Quad 2-Input NAND Gate With Open Collectors Outputs

7403 DIP Quad 2-Input NAND Gate With Open Collectors Outputs

The 2-Input NAND Gate is a key component in digital logic. This 7403 DIP Quad version has four independent gates. Each gate has two inputs. The outputs are open collector. This design allows wired-AND connections. It is perfect for hobbyists and engineers.

This 2-Input NAND Gate performs the NAND logic function. It outputs a low signal only when both inputs are high. The open collector output can sink current from an external load. You can connect it to a higher voltage supply. This makes level shifting easy. You can also tie multiple outputs together. This creates a wired-AND configuration. It reduces the need for extra gates. The 2-Input NAND Gate is versatile for many designs. It works well in clock circuits and data processing. The TTL compatibility ensures smooth integration. You can use it with other 74 series chips. The 14-pin DIP package fits standard breadboards. It is also easy to solder on PCBs. The low power draw keeps your project efficient. The high noise immunity prevents false triggers. This 2-Input NAND Gate is a reliable building block.

Key Features

• Four independent 2-input NAND gates in one 14-pin DIP package
• Open collector outputs for wired-AND and level shifting
• Standard TTL logic compatible with 5V supply
• Wide operating temperature range for various environments
• Low power consumption and high noise immunity
• Easy to use in breadboards, perfboards, and PCBs

Use Cases

This 2-Input NAND Gate suits many buyers. Electronics hobbyists use it for custom logic projects. Students learn digital design with it. Engineers prototype circuits quickly. It works in industrial control systems. It is ideal for timing and pulse generation. You can build counters and flip-flops. It also helps in data selection and routing. The open collector output drives relays and LEDs. This 2-Input NAND Gate is a staple in any toolkit.

Order your 7403 DIP Quad 2-Input NAND Gate now from Electra Store. Get fast shipping and reliable quality. Build your next project with confidence. Buy today!
