7465 DIP 4-2-3-2 Input AND-Or-Invert Gate With Open Collector Output

7465 DIP 4-2-3-2 Input AND-Or-Invert Gate With Open Collector Output

The AND-Or-Invert Gate 7465 DIP is a versatile logic IC. It features 4-2-3-2 inputs and an open collector output. This gate is perfect for complex logic circuits. Engineers and hobbyists rely on it for reliable performance. It works well in digital systems.

This AND-Or-Invert Gate combines multiple logic functions into one chip. It performs AND operations on four groups of inputs. The groups have 4, 2, 3, and 2 inputs each. Then it ORs those results together. Finally it inverts the output. This saves space on your board. It reduces the number of chips you need. The open collector output is a key advantage. It lets you connect multiple outputs to one line. This is called a wired-OR connection. You can also drive LEDs or relays directly. The gate operates at standard TTL voltage levels. This means it works with most 5V logic systems. It is a robust and dependable component.

Key Features

• 4-2-3-2 input configuration for flexible logic design
• Open collector output for easy bus sharing
• Standard TTL compatibility for broad use
• DIP package for easy breadboarding and prototyping
• Reliable performance from Electra Store
• Low power consumption for efficient circuits

Use Cases

This AND-Or-Invert Gate is for many types of users. Digital designers use it in complex logic trees. Students learn Boolean algebra with it. Hobbyists build custom controllers and gadgets. Engineers use it in industrial automation systems. It is also great for retro computing projects. Anyone who needs a compact logic solution will benefit. The open collector output is ideal for bus systems. It works well in multiplexed displays and data selectors. This gate is a staple in any electronics lab.

Order the 7465 DIP AND-Or-Invert Gate today. Electra Store offers fast shipping and quality parts. Upgrade your project with this reliable IC. Buy now and build better circuits. You will love the performance and versatility. Get your AND-Or-Invert Gate now. It is ready to ship to you. Start your next project with confidence.
