TIL113 Optocoupler / Phototransistor Opto-isolator – 6-Pin DIP

TIL113 Optocoupler – High Isolation 6-Pin DIP

The TIL113 Optocoupler is a reliable opto-isolator. It uses an NPN phototransistor output. This part provides up to 5000V RMS isolation. It is perfect for engineers and hobbyists. Use it to protect sensitive circuits from high voltage.

This optocoupler works with TTL and CMOS logic. It needs low input current to operate. The fast switching speed ensures clean signals. The standard 6-pin DIP package is easy to solder. It fits many breadboards and PCBs.

The TIL113 Optocoupler bridges two separate circuits safely. It uses light to transfer signals. This prevents high voltage from damaging low voltage parts. The internal LED shines on the phototransistor. That creates electrical isolation between input and output. You can drive it with just a few milliamps. It responds quickly to changes in input. This makes it ideal for noisy environments. The 5000V RMS rating gives you peace of mind. It meets safety standards for many applications. The 6-pin DIP layout is industry standard. You can replace older optocouplers easily. It works with both analog and digital signals. The output can sink or source current. This flexibility helps in many designs.

Key Features

• High isolation voltage: up to 5000V RMS for safety
• NPN phototransistor output for digital or analog signals
• TTL and CMOS logic compatible for easy integration
• Fast switching speed for reliable performance
• Low input current required for operation
• Standard 6-pin DIP plastic package for prototyping

Use Cases

The TIL113 Optocoupler is great for signal isolation. Use it in microcontroller projects. It works well in relay driver circuits. It also suppresses noise in communication lines. Engineers use it in industrial controls and power supplies. Hobbyists choose it for home automation. It protects Arduino and Raspberry Pi inputs. It also works in medical devices. The TIL113 Optocoupler is common in motor controllers. It isolates feedback signals in power systems. Anyone needing clean signal transfer buys this part. It is a top choice for safety-critical designs.

Buy the TIL113 Optocoupler today. It offers reliable isolation and fast switching. Perfect for your next project. Order now from Electra Store. You will get genuine components. They are tested for quality. Add the TIL113 Optocoupler to your cart now. Do not wait. Start your build today. Your circuits deserve the best protection. Click to order the TIL113 Optocoupler now.
