4024 DIP 7-Stage Binary Ripple Counter

4024 DIP 7-Stage Binary Ripple Counter

The 7-Stage Binary Ripple Counter is a reliable CMOS IC. It counts pulses in digital circuits. This DIP-14 package is easy to use. It works well for hobbyists and engineers. You get seven stages of binary counting. It is ideal for frequency division.

This 7-Stage Binary Ripple Counter works by cascading flip-flops. Each flip-flop divides the input frequency by two. The output from each stage is a binary bit. The first stage gives the least significant bit. The seventh stage gives the most significant bit. You can count up to 128 pulses. The ripple effect means each stage triggers the next. This design is simple and efficient. It works with TTL and CMOS logic. The chip handles input frequencies up to 12 MHz. It operates from 3V to 15V. This makes it versatile for many projects. The counter resets to zero with a clear pin. You can chain multiple chips for more stages. This expands your counting range easily. The 7-Stage Binary Ripple Counter is a workhorse for digital design.

Key Features

• Seven binary stages for up to 128 counts
• Wide supply voltage range from 3V to 15V
• High noise immunity for reliable operation
• Standard DIP-14 footprint fits breadboards
• Low power consumption extends battery life
• Master reset pin for instant clearing

Use Cases

Build digital clocks with this 7-Stage Binary Ripple Counter. Create frequency dividers for audio projects. Use it in educational kits to teach binary counting. It is perfect for robotics and automation. Hobbyists love its simplicity. Engineers use it for timing circuits. Students learn counter basics with it. It works in alarm systems too. The 7-Stage Binary Ripple Counter fits many applications. You can make a stopwatch or a timer. It helps in pulse counting for sensors. Use it in vending machines or traffic lights. The chip is great for DIY electronics. It is a staple for any workbench.

Order your 7-Stage Binary Ripple Counter today. Electra Store ships fast. Upgrade your circuit designs now. Get reliable performance every time. This 7-Stage Binary Ripple Counter is in stock. Add it to your cart now. You will love the quality. Start your next project today.
