4072 DIP Dual 4-Input Or Gate

4072 DIP Dual 4-Input OR Gate

The 4072 DIP Dual 4-Input OR Gate is a versatile CMOS logic IC. It belongs to the 40 Series family. This chip contains two independent 4-input OR gates. It is ideal for digital electronics projects. Hobbyists and engineers love its reliability.

This OR gate outputs a high signal when any input is high. It works with a wide voltage range. The DIP-14 package makes it easy to use on breadboards. You can integrate it into many circuits. It is a must-have for logic design.

The Dual 4-Input OR Gate performs a simple but vital logic function. It combines up to four signals into one output. The output goes high if any input is high. This makes it perfect for creating complex logic trees. You can cascade multiple chips for more inputs. The CMOS design ensures very low power draw. It also offers excellent noise immunity. This means stable performance even in noisy environments. The wide voltage range from 3V to 15V adds flexibility. You can use it with both 5V and 12V systems. The standard DIP-14 footprint fits common breadboards and sockets. This makes prototyping quick and easy. The Dual 4-Input OR Gate is a reliable workhorse for any digital circuit.

Key Features

• Dual 4-input OR gates in one compact DIP-14 package
• Wide supply voltage range from 3V to 15V
• Low power consumption typical of CMOS technology
• High noise immunity for stable operation
• Standard 40 Series pinout for easy replacement
• RoHS compliant and lead-free

What's Included

• One 4072 DIP Dual 4-Input OR Gate IC
• Anti-static protective packaging
• Product datasheet with pinout diagram
• Electra Store quality guarantee

Use Cases

This Dual 4-Input OR Gate is perfect for many buyers. Hobbyists use it in DIY alarm systems. It combines multiple sensor inputs into one trigger. Engineers choose it for data selector circuits. It works well in control logic for machines. Students use it in educational kits to learn logic. It is great for prototyping on breadboards. The low power draw suits battery-powered devices. You can also use it in audio mixers or signal combiners. Anyone building digital circuits will find it useful. The Dual 4-Input OR Gate is a staple for logic design projects.

Order the 4072 DIP Dual 4-Input OR Gate from Electra Store today. Add this essential component to your kit. Enjoy fast shipping and great support. Upgrade your projects now! This Dual 4-Input OR Gate will simplify your designs. It offers reliable performance every time. Don't wait to complete your circuit. Click to order and get building today.
